Product Standard/s

BS 546

Terminal Capacity L&N

3 x 1.5, 2 x 2.5 mm²

Terminal Capacity E

3 x 1.5, 2 x 2.5 mm²

Frequency

50 Hz

LRV Value

73

CE Conformity

Yes

WEEE Symbol

Yes

UKCA Conformity

Yes

Model

British Standard

Protective contact

No

Number of active pins (round)

3

Number of active pins (flat)

0

With signal lamp

No

With built-in USB power supply

No

Number of units

1

Number of modules (module system)

0

Number of socket outlets switchable

1

Number of phases

2

Imprint/indication

Other

Connection type

Screwed terminal

With hinged lid

No

With enhanced contact protection

Yes

Label space/information surface

Yes

Colour

White

Lockable

No

Insulated mounting

Yes

With function lighting

No

Fault current protection

No

Special power supply

No special power supply

Mounting method

Surface mounted (plaster)

Type of fastening

Mounting with screw

Material

Plastic

Material quality

Other

Halogen free

Yes

Surface protection

Other

Surface finishing

Glossy

Anti-bacterial treatment

No

With on/off switch

Yes

Nominal current

15 A

Nominal voltage

250 V

Suitable for degree of protection (IP)

IP2X

Impact strength

IK02

Width of device

85 mm

Height of device

85 mm

Min. depth of built-in installation box

35 mm
